Project Description
TX plus Portable printer
TX plus Portable printer wireless
TX plus Trusty handheld coding machine
| Model | TX plus |
| Operating system | LINUX3.4 |
| Processor/Memory | CORTEX-A7/3GB |
| Screen | 5 inch capacitive touch screen |
| Body material | ABS |
| Resolution | 300DPI/600DPI plus black concentration level 1-10 |
| Printing content | Text, date, LOGO, QR code, DM code, barcode, etc. |
| Character type | High-definition printing character, dot matrix font, Simplified, Traditional Chinese and English |
| Variable print content | Variable one-dimensional code, two-dimensional code, DM code, variable text |
| Supported file format | TXT & XLSX (text) / BMP monochrome or 24-bit color (picture) |
| Printing direction | adjusted within 360 degree, meet all kinds of production needs |
| Printing height | 2mm～12.7mm / 2mm～25.4mm (Adjustable printing height) |
| Printing length | Up to 2m per message |
| Printing distance | 1-10mm Mechanical Adjustment (the best distance between the nozzle and printed object is 2～5mm) |
| Printing line | 1-8 lines (adjustable) |
| Counter | Up to 8 bits |
| Time variable | Contains seconds |
| Printing speed | 60m/min |
| Print segment | Up to 5 segments |
| Peripheral interface | USB interface & RS232 interface (Support electric eye & Synchronizer) |
| Operating language | Chinese, English, Spanish, Portuguese, Arabic, Russian, French, Korean, Japanese, Thai, etc.(One key switch) |
| Battery voltage | DC16.8 lithium battery, print continuously more than 10 hours and 20 hours standby |
| Power consumption | the average power consumption is lower than 5W |
| Ink type | Quick-dry environmental ink, water-based ink and oily ink |
| Ink color | black, white, red, blue, yellow, green, invisible |
| Ink volume | 42ml(usually can print 800,000 characters) |
| Working environment | Temperature:0 -40degree; Humidity: 10% – 80% |
| Printing material | board, carton, stone, pipe, cable, metal, plastic product, electronic, the fiber board, light steel keel, aluminum foil, etc. |
| Printer dimensions | 140mm*100mm*240mm |
| Net weight | 0.996kg |
Product Features
Variable QR code,barcode,DM code etc.
Can realize serial port,Bluetooth,wifi communication
Up to 20 kinds of languages
Both online and handheld
